Who is SEGGER’s most demanding customer?

As the main debugger task has become more and more time critical due to target devices get faster, working with a typical 1 millisecond system tick became a critical bottleneck. So, the J-Link team put pressure on the embOS developers to come up with a solution and

embOS-Ultra was born offering processor clock cycle resolution for time critical events such as task delays and software timers. This means on a typical low-end 100MHz system, that would be 10ns, with a task switch close to 300 cycles, that would make 3µs for a full context switch. It also allows periodic tasks to be scheduled faster than 1KHz and with finer resolution, such as 5KHz.

J-Link and J-Trace it all is about fast signal generation, so higher precision for the rising signal means higher possible speeds.

By eliminating the periodic tick interrupt, embOS-Ultra reduced the CPU load and also saved energy. Considering that billions of devices currently use a traditional RTOS, this represents huge potential energy savings world-wide.

Gone are the days of UART communication when connecting to a debugger, so a tight, efficient and flexible USB Device stack was needed. Again, the natural choice was to use the SEGGER emUSB-Device offering a full range of speeds including Full (12Mb/s), High (480Mb/s) and SuperSpeed (5Gb/s).

As development teams are now more often home based or at least based in multiple locations (especially post COVID) the ability to make a remote connection to a debugger and often limited target hardware is important, making the J-Link & J-Trace remote connectivity extremely valuable.

To help unlock remote debug capability, the SEGGER emNet was developed to implement a small footprint TCP/IP connection along with the industry standard protocols such as IPV4/6, IEEE 1588 PTP, DHCP and extensions such as MQTT.

Fast reliable communication stacks are essential when looking at real time streaming trace offered for example by J-Trace. Dropping any trace data could mean hiding that elusive bug or failing to tune an embedded design for the very best performance.

As the ever-expanding list of silicon suppliers release new devices (on an almost weekly basis), along with product enhancements and new features, it opened up the need for remote update management of the embedded J-Link firmware. Multiple software components were needed to manage this securely, efficiently and reliably using industry standard protocols.

Again, the J-Link developers turned to the SEGGER software team’s middleware, such as emLoad and emFile.

It quickly became clear that data compression would be of an advantage to reduce download times and data storage requirements, hence the development of emCompress that allows firmware images on a host to be compressed and then decompressed on the embedded side. This not only minimizes the download speed but also reduces the memory requirements during firmware updates as images can be decompressed directly into code flash. High end J-Link and J-Trace units run time FPGA images are decompressed at power up, saving considerable non-volatile storage.

It is an unfortunate truth that embedded firmware images are open to abuse during manufacture and while performing in field updates. J-Link itself has historically been vulnerable to cloning and action was needed to secure the valuable firmware during manufacture as well as assuring it would only run on SEGGER produced hardware.

Once more, the SEGGER software team developed solutions to prohibit cloning during manufacture as well as validation of firmware and hardware combinations during field updates.

The emSecure software package is a digital signature suite that allows the creation and verification of digital assets, making it impossible to create a clone by simply copying hardware and firmware of an embedded device. That is of course just the beginning: it also secures firmware updates to embedded devices and authenticates licenses, serial numbers and other sensitive data.
