SEGGER - emNet Ethernet Stack

emNet NetBIOS

The emNet NetBIOS implementation is an optional extension which can be seamlessly integrated into your application. It combines a maximum of performance with a small memory footprint. The NetBIOS implementation allows an embedded system to resolve NetBIOS names in the local area network.

  • Low memory footprint
  • Seamless integration with the emNet TCP/IP stack
  • Client based NetBIOS name resolution
  1. 1.NetBIOS Backgrounds
  2. 2.Requirements
  3. 3.Resource usage
    1. 3.1.ROM Usage on an ARM7 System
    2. 3.2.ROM Usage on a Cortex-M3 System
    3. 3.3.RAM Usage
  4. 4.Relevant parts

NetBIOS Backgrounds

The Network Basic Input/Output System protocol is an API on top of the TCP/IP protocol, it provides a way of communication between separate computers within a local area network via the session layer.

Using NetBIOS, an emNet application can resolve a NetBIOS name to an IP address in the local area network.

netbios background

Requirements

The emNet NetBIOS implementation requires the emNet TCP/IP stack.

Resource usage

The ROM usage depends on the compiler options, the compiler version and the used CPU. The memory requirements of the NetBIOS module presented in the tables below have been measured on an ARM7 and a Cortex-M3 system. Details about the further configuration can be found in the sections of the specific example.

ROM Usage on an ARM7 System

The following resource usage has been measured on an ARM7 system using IAR Embedded Workbench V6.30.6, Thumb mode, no interwork, size optimization.

Add-onROM
emNet NetBIOS moduleApproximately 0.8 KByte

ROM Usage on a Cortex-M3 System

The following resource usage has been measured on a Cortex-M3 system using IAR Embedded Workbench V6.30.6, size optimization.

Add-onROM
emNet NetBIOS moduleApproximately 0.7 KByte

RAM Usage

Add-onROM
emNet NetBIOS moduleApproximately 26 Bytes

Relevant parts

The NetBIOS module implements the relevant parts of the following Request For Comments (RFC).

RFC#Description
[RFC 1001]NetBIOS concepts and methods

Direct download: ftp://ftp.rfc-editor.org/in-notes/rfc1001.txt

[RFC 1002]NetBIOS detailed specifications

Direct download: ftp://ftp.rfc-editor.org/in-notes/rfc1002.txt
